EF-R3Structural RepairEN 1504-3 — R3

EuroFix Repair Mortar R3

Fibre-reinforced, non-shrink structural mortar for repairing concrete and façades — columns, beams, spalled concrete and exposed rebar zones.

CE
EN 1504-3
R3
Download TDS Sheet
Application guides for this product
Repairing damaged concrete and exposed reinforcement→

Technical Specifications

Packaging

25 kg bag

Mix Ratio

≈ 3.5–4 L water / 25 kg

Bond Strength

Compressive ≥ 30 MPa

Application

Layer 5–40 mm/pass, fibre-reinforced

Drying Time

Initial set ≈ 40 min

Detailed Product Description

A fibre-reinforced, non-shrink structural repair mortar (R3) for repairing and reconstructing concrete and façades: columns, beams, spalled concrete and exposed-rebar zones. Classified to EN 1504-3 — R3 for structural reinstatement.
High-strength cement, graded quartz sand, polymer fibres and shrinkage-compensating, adhesion-improving additives.
Remove all weak, loose concrete down to a sound substrate. Clean exposed rebar of rust and treat with a protective coat. Pre-wet the surface to a saturated surface-dry (SSD) condition before application.
Add about 3.5–4 L of clean water per 25 kg bag and mix with a slow drill to a lump-free, homogeneous paste. Let it rest 2 minutes, then re-stir. Pot life is limited; mix only what can be applied.
Apply in passes of 5–40 mm, compacting well to ensure full contact and full encasement of the rebar. Finish and smooth before set. Protect from rapid drying by moist curing. Initial set ≈ 40 min; compressive strength ≥ 30 MPa.
Contains cement which produces an alkaline reaction with moisture. Wear protective gloves and safety goggles. In case of contact with eyes, rinse immediately with plenty of water and seek medical advice.
Store in original unopened bags, in a dry place elevated from the ground on wooden pallets. Shelf life is 12 months from the production date printed on the packaging.

Related Products

EuroFix Acrylic Primer
Primer

EuroFix Acrylic Primer

Deep penetrating acrylic primer to stabilize substrates, regulate absorption, and boost adhesion.

View Details
EuroFix Contact Primer
Betokontakt

EuroFix Contact Primer

Quartz-sand modified bonding agent (Betokontakt) for smooth concrete surfaces.

View Details
EuroFix Waterproofing Compound
Waterproof

EuroFix Waterproofing Compound

Ready-to-use elastomeric liquid waterproofing membrane for wet areas, bathrooms, and balconies.

View Details

Frequently asked questions

What is EuroFix Repair Mortar R3 used for?

A fibre-reinforced, non-shrink structural repair mortar, classified EN 1504-3 — R3, for repairing and reconstructing concrete and façades. Designed for columns, beams, spalled concrete and exposed-rebar zones, it delivers ≥ 30 MPa compressive strength and reliable, code-compliant performance for structural works and tenders. Concrete columns and beams · Façades and spalled concrete surfaces · Exposed-rebar repair zones · Reconstruction of degraded concrete sections · Structural projects and certified tenders

What is the European classification of EuroFix Repair Mortar R3?

EuroFix Repair Mortar R3 is classified EN 1504-3 — R3. Declared certifications: CE · EN 1504-3 · R3.

What is the Mixing ratio of EuroFix Repair Mortar R3?

Mixing ratio: ≈ 3.5–4 L water per 25 kg bag.

What is the Compressive strength of EuroFix Repair Mortar R3?

Compressive strength: ≥ 30 MPa.

What is the Layer thickness of EuroFix Repair Mortar R3?

Layer thickness: 5–40 mm per pass.

What is the Reinforcement of EuroFix Repair Mortar R3?

Reinforcement: Fibre-reinforced.

What is the coverage of EuroFix Repair Mortar R3 per square metre?

Per mm thickness per m²: ≈ 1.8 kg/m²/mm · 20 mm layer: ≈ 36 kg/m² · 25 kg bag covers: ≈ 14 L fresh mortar

What pack size does EuroFix Repair Mortar R3 come in?

25 kg bag

How is EuroFix Repair Mortar R3 stored and what is its shelf life?

Store in original sealed bags in a dry place, raised off the ground on wooden pallets. Shelf life 12 months from the production date printed on the packaging.
